Product Details
Place of Origin: China
Brand Name: HUAXING
Certification: MSDS
Model Number: HX12200
Payment & Shipping Terms
Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Carton
Delivery Time: 15days
Payment Terms: T/T, L/C
Supply Ability: 10000pcs per month
Voltage: |
12.8V |
Capacity: |
200Ah |
Max Charge Current:: |
100A |
Max Discharge Current:: |
100A |
Peak Current:: |
200A |
OEM: |
YES |
ODM: |
YES |
Life Cycles: |
Over 2000times |
Plastic Case: |
520*265*220mm |
Light Weight: |
28kg |
Voltage: |
12.8V |
Capacity: |
200Ah |
Max Charge Current:: |
100A |
Max Discharge Current:: |
100A |
Peak Current:: |
200A |
OEM: |
YES |
ODM: |
YES |
Life Cycles: |
Over 2000times |
Plastic Case: |
520*265*220mm |
Light Weight: |
28kg |
12V 200AH LiFePo4 battteries Safety Characteristics
12V 200AH LiFePo4 battteries specification
| Battery Pack Parameter | |||
| 1 | Nominal Voltage | 12.8V | |
| 2 | Voltage Range | 10～14.6V | Cells voltage range: 2.5-3.65V |
| 3 | Nominal Capacity | 200Ah | 0.5C rate,25℃ |
| 4 | Nominal Energy Capacity | 2560Wh | |
| 5 | Max. Charge Current | 150A | |
| 6 | Max. Continuous Discharge Current | 150A | |
| 7 | Peak Discharge Current | 300A | Duration time: 5S |
| 8 | Cycle Life of Battery Pack | Over 2000 | at 80 % DOD, 25℃ |
| 9 | Total Weight | 27.5kg | |
| 10 | Humidity | 10%-90% | |
| 11 | Cooling Method | Natural Cooling | |
| 12 | Working Temperature | Charge: 0℃～45℃, Discharge: -20℃～60℃ | |
| 13 | Smart Functions | With Bluetooth and mobile phone APP connection; Mobile phone APP display: battery pack voltage, single cell voltage, working current, SOC, cycle number, temperature and so on. | |
Bluetooth BMS specification(For IOS and Andorid system)
| Item | Content | Criterion |
| Charge and Discharge Port | Shared | |
| Communication | Bluetooth | |
| Parallel Connection | Not allowed | |
| Serial Connection | Max. 4pcs | |
| Normal Current | Charge Current | ≤200A |
| Discharge Current | ≤200A | |
| Over charge Protection | Charge Voltage | 14.6V |
| Over charge detection voltage | 3.80±0.05V | |
| Over charge detection delay time | 1S | |
| Over charge release voltage | 3.60±0.05V | |
| Over discharge protection | Over discharge detection voltage | 2.00V±0.10V |
| Over discharge detection delay time | 1S | |
| Over discharge release voltage | 2.30±0.10V | |
| Over current protection | Over current detection current | 440±40A |
| Over current detection delay time | 1S | |
| Over current release condition | Disconnected loading or charger | |
| Short circuit protection | YES | |
| Temperature protection | YES | |
Our life cycle tests for our lifepo4 battery:
Huaxing other 12V LiFePo4 battery
| 12.8V LiFePO4 Battery Pack | |||||||
| Battery Type | 12V12Ah | 12V20Ah | 12V50Ah | 12V75Ah | 12V100Ah | 12V200Ah | 12V300AH |
| Cell Type | 3.2V/6.0Ah | 3.2V/5.5Ah | 3.2V/5.5Ah | 3.2V/5.5Ah | 3.2V/5.5Ah | 3.2V/5.5Ah | 3.2V/6.0Ah |
| Nominal Voltage(V) | 12.8 | ||||||
| Nominal Capacity (Ah) | 12 | 20 | 50 | 80 | 100 | 200 | 300 |
| Charge Voltage (V) | 14.6 | ||||||
| Charge Current (A) | ≤10 | ≤20 | ≤50 | ≤75 | ≤100 | ≤150 | ≤150 |
| Discharge Current (A) | ≤10 | ≤20 | ≤50 | ≤75 | ≤100 | ≤150 | ≤150 |
| Weight(kg) | 1.5 | 3 | 7.5 | 11.5 | 14 | 29 | 40 |
| Dimensions(L*W*H)(mm) | 151*98*98 | 181*76*166 | 197*165*170 | 208*169*260 | 324*172*214 | 520*265*220 | 520*265*220 |
| Operation Temperature | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ |
| Housing Material | ABS | ||||||
| Protection Functions | short circuit, over charge, over discharge, over current, over temperature | ||||||
Product Picture
Package Information:
| DESCRIPTION | QUANTITY/CTN | PACKAGE | GROSS WEIGHT | NET WEIGHT | DIMS(m3) |
| (PCS) | CARTONS SIZE(MM) | (KG) | (KG) | ||
| 12V100AH LiFePo4 Battery | 1 | 460*250*220 | 14 | 13 | 0.03 |
| 12V200AH LiFePo4 Battery | 1 | 575*325*270 | 29 | 28 | 0.05 |
| 12V300AH LiFePo4 Battery | 1 | 575*325*270 | 40 | 39 | 0.05 |
