Product Details
Place of Origin: China
Brand Name: HUAXING
Certification: MSDS
Model Number: HX311
Payment & Shipping Terms
Minimum Order Quantity: 100pcs
Price: Negotiation
Packaging Details: Carton
Delivery Time: 15days
Payment Terms: T/T, L/C
Supply Ability: 10000pcs per month
Voltage: |
3.2V |
Capacity: |
12AH |
Max Charge Current:: |
5A |
Max Discharge Current:: |
5A |
Peak Current:: |
10A |
OEM: |
YES |
ODM: |
YES |
Life Cycles: |
Over 2000times |
Material: |
LiFePo4 |
Application: |
Car Audio System，Telecommunication Equipment |
Voltage: |
3.2V |
Capacity: |
12AH |
Max Charge Current:: |
5A |
Max Discharge Current:: |
5A |
Peak Current:: |
10A |
OEM: |
YES |
ODM: |
YES |
Life Cycles: |
Over 2000times |
Material: |
LiFePo4 |
Application: |
Car Audio System，Telecommunication Equipment |
| Battery type | 3.2V11Ah Lifepo4 battery | |
| 1 | Nominal Voltage(V): | 3.2V |
| 2 | Voltage Range(V): | 2-3.65V |
| 3 | Nominal Capacity(Ah): | 11AH |
| 4 | Max. Charge Current(A): | 5A |
| 5 | Max. Continuous Discharge Current(A): | 5A |
| 6 | Peak Discharge Current(A): | 10A |
| 7 | Cycle Life(Times): | Over 2000times |
| 8 | Charge way: | CC/CV |
| 9 | Dimension(L*W*H): | Customized |
| 10 | Working Temperature: | Charge: 0℃～45℃ Discharge: -20℃～60℃ Storage: -20℃～45℃ |
Our safety tests for our lifepo4 battery:
Our life cycle tests for our lifepo4 battery:
Related lifepo4 battery
Certificate
Application
Our company other hot sales products
1)32700 3.2V 6AH LFP cell.
2)12V 50&100&200&300AH with ABS package to replace tranditional SLA battery.
3)48V50&100AH with communication BMS for telecom tower.
4)5KWh and 10KWH lithium battery pack for home energy storage system.
5)6.4V&9.6V&12V&24V 6-30AH with soft pvc package battery pack for emergency lighting,LED light,flashing light,solar street lighting,and others.
6)51.2V 12&18&55Ah,64V20&24Ah,76.8V 24&36Ah for e-bike,motorcycle and other low speed vehicles.
About us:
HUAXING NEW ENERGY is a group company.
Our Factory Environment: Welcome to visit us!
The comparison between LFP and NCM
| Items | LiFePO4 Battery | LiNiCoMnO2 Battery(NCM) |
| Nominal Voltage | 3.2V | 3.7V |
| Discharging Rate |
≤10C
|
≤5C |
| Safety | Much more safe at high temperature, or in an accident, no explosion, no fire, successfully pass the safety test | Less safety performance at high temperature, or in an accident. difficult to pass the safety test, such as nail penetration test |
| Working Temperature | -20-70℃. | -20-55℃. |
| Cycle Performance |
More than 4000 cycles at 1C, 80%DOD. The EOL is still 100% after 500 cycles |
About 1500 cycles at 1C, 80%DOD. The EOL is below 98% after 500 cycles |
| Stability | The Olivine type crystal structure is the most stable one, and not decompose in high temperature | The Layer type crystal structure is less stable, easy to decompose and collapse |
| Material | Does not contain any heavy metals and rare metals, raw material can be easily obtained | Co is rare metal, and very limit resource on the globe |
