BMS Built In Lifepo 4100ah 12v Lifepo4 Batteries Pack Lithium Ion Battery ABS Case

Product Details

Place of Origin: CHINA

Brand Name: Huaxing

Certification: UL\ROHS\CE\CB

Model Number: HX-12100

Payment & Shipping Terms

Minimum Order Quantity: 1pcs

Price: TBD

Packaging Details: Carton

Delivery Time: 30days

Payment Terms: T/T, L/C

Supply Ability: 100000pcs per month

Get Best Price
Product Details
High Light:

4100ah 12v Lifepo4 Batteries

,

BMS 12v Lifepo4 Batteries

Name:
HX-12100
Nominal Voltage:
12.8V
Voltage Range:
10~14.6V
Nominal Capacity:
100Ah
Minimum Capacity:
95Ah
Max. Continuous Discharge Current:
100A
Peak Discharge Current:
200A
Total Weight:
13.0kg
Working Temperature:
Charge: 0℃~45℃ Discharge: -20℃~60℃ Storage: 0℃~45℃
Name:
HX-12100
Nominal Voltage:
12.8V
Voltage Range:
10~14.6V
Nominal Capacity:
100Ah
Minimum Capacity:
95Ah
Max. Continuous Discharge Current:
100A
Peak Discharge Current:
200A
Total Weight:
13.0kg
Working Temperature:
Charge: 0℃~45℃ Discharge: -20℃~60℃ Storage: 0℃~45℃
Product Description

BMS built-in long life lifepo4 12v 100ah deep cycle lithium-ion battery lifepo4 battery pack ABS Case

Lead Acid 12V 100AH Lifepo4 Battery Pack UL ROHS CE CB Certificated



12V100AH LIFEPO4 battery



A high-performance power storage solution designed to meet your energy needs with reliability and efficiency. This lithium iron phosphate (LiFePO4) battery offers exceptional performance and a range of advantages for various applications.

The 12V 100Ah LiFePO4 battery provides a reliable and stable power supply for a wide range of devices and systems. It is particularly well-suited for applications such as solar energy storage, marine equipment, recreational vehicles, and backup power systems.

One of the standout features of the 12V 100Ah LiFePO4 battery is its impressive cycle life. It is capable of withstanding a large number of charge and discharge cycles without experiencing a significant reduction in performance. This extended cycle life ensures durability and longevity, reducing the need for frequent battery replacements and offering long-term cost savings.



Sr. NO. Item Criterion Note
Cell Parameter
1. Battery Type LiFePO4 Battery
2. Rated Voltage/Capacity 3.20V/6.0Ah
3. Voltage Range 2.00V-3.65V
4. Weight 0.143kg
5. Size Φ(32.0±0.5)* H(70.2±0.4)mm
6. Cathode Material LiFePO4
7. Anode Material Graphite
8. Electrolyte Material LiPF6
9. Working Temperature Charge: 0℃~45℃, Discharge: -20℃~60℃
10. Charge Retention 95% (25℃, 28 days)
11. Cycle Times over 2000 cycles(0.2C cycle, 25℃,capacity retention 80%













12.









Cell Discharge Curve at

-20℃, 10℃, 0℃, 25℃, 45℃,

65℃

BMS Built In Lifepo 4100ah 12v Lifepo4 Batteries Pack Lithium Ion Battery ABS Case 0
Battery Pack Parameter
1. Nominal Voltage 12.8V
2. Voltage Range 10~14.6V

Cells voltage range: 2.5-3.65V



3. Nominal Capacity 100Ah
4. Minimum Capacity 95Ah
5. Max. Charge Current 100A
6. Max. Continuous Discharge Current 100A
7. Peak Discharge Current 200A Duration time: 1S
8. Cycle Life of Battery Pack Over 2000 At 0.5C, 80 % DOD, 25℃
9. Total Weight 13.0kg
10. Cooling Method Natural Cooling





11.





Working Temperature

Charge: 0℃~45℃

Discharge: -20℃~60℃

Storage: 0℃~45℃



BMS Specification

Item Content Criterion
Charge and Discharge Port Shared
Communication None
Parallel Connection Max. 2pcs
Serial Connection Max. 4pcs
Normal Current Charge Current ≤100A
Discharge Current ≤100A







Over charge Protection









Over discharge protection

Over charge detection voltage 3.75±0.05V
Over charge detection delay time 1.0s
Over charge release voltage 3.55±0.05V
Over charge release condition Cut off charger
Maximum charge voltage 3.65±0.05V
Over discharge detection voltage 2. 1V±0.05V
Over discharge detection delay time 1.0s
Over discharge release voltage 2.7V±0. 10V



Over current protection

Over current detection current 200±10A
Over current detection delay time 1.0s
Over current release condition Cut load
Short circuit protection YES
