Product Details
Place of Origin: China
Brand Name: Huaxing
Certification: MSDS
Model Number: HX24100
Payment & Shipping Terms
Minimum Order Quantity: 10
Price: Negotiation
Packaging Details: 1 pks per UN carton
Delivery Time: 20-25 days
Supply Ability: 100 pks per day
Material: |
LiFePo4/Graphite |
Nominal Voltage: |
25.6V |
Nominal Capacity: |
100Ah |
Max Constant Current: |
100A |
Max Charge Voltage: |
29.2V |
Cut Off Voltage: |
20V |
Cycles Life: |
2000 Cycles |
Warranty: |
2 Years |
Material: |
LiFePo4/Graphite |
Nominal Voltage: |
25.6V |
Nominal Capacity: |
100Ah |
Max Constant Current: |
100A |
Max Charge Voltage: |
29.2V |
Cut Off Voltage: |
20V |
Cycles Life: |
2000 Cycles |
Warranty: |
2 Years |
Long Clycle Life Lithium Ion battery pack 24V LiFePO4 Batteries 100AH for Solar Power Bank Energy Storage
Products Features
These batteries are superior to lead-acid batteries because they have
One kind. Extremely safe and stable chemical composition: The built-in PCB
and/or BMS can balance and protect the battery.
b. Long life: It can be recycled, preferably 2000 times, which is 8 times that of lead-acid batteries.
C. Lighter weight, best power-to-weight ratio: 1/3 of the weight of lead-acid batteries.
d. Good high temperature and high temperature resistance
e. The self-discharge rate is low, less than 3% per month.
F. There is no memory effect and efficient charging.
G. Environmental protection: Clean and green energy will not pollute our environment.
1.Various sizes, models and capacities can be designed and customized, and OEM
customization is welcome.
2.Large capacity, light weight and long use time.
3.Long cycle life and high safety performance.
24V200ah LiFePo4 Batteries specification
|
No. |
Item |
General Parameter |
|
1 |
Model |
HX24100 |
|
2 |
Standard Capacity |
100AH |
|
3 |
Rated Voltage |
25.6V |
|
4 |
Max Charge Voltage |
29.2V |
|
5 |
Discharge Cut Off Voltage |
20V |
|
6 |
Standard Charge Current |
100A |
|
7 |
Max Continuous Discharge Current |
100A |
|
8 |
Peak Instant Discharge Current |
100A with 5S |
|
9 |
Dimension(ABS) |
578*410*198mm |
|
10 |
Total weight(Approx.) |
65kg |
|
11 |
Operate Temperature |
-20°C~60°C |
|
12 |
Built-in BMS |
YES |
|
13 |
Cycle Times |
2000 cycles |
Main Applications:
24V Stanadrd LiFePo4 battery
| 24V LiFePO4 Battery Pack | |||||||
| Battery Type | 24V6Ah | 24V10Ah | 24V20Ah | 24V30Ah | 24V50Ah | 24V100Ah | 24V130AH |
| Cell Type | 3.2V/6.0Ah | 3.2V/5.5Ah | 3.2V/5.5Ah | 3.2V/5.5Ah | 3.2V/5.5Ah | 3.2V/5.5Ah | 3.2V/6.0Ah |
| Nominal Voltage(V) | 12.8 | ||||||
| Nominal Capacity (Ah) | 6 | 10 | 20 | 30 | 50 | 100 | 130 |
| Charge Voltage (V) | 14.6 | ||||||
| Charge Current (A) | ≤6 | ≤10 | ≤20 | ≤30 | ≤50 | ≤100 | ≤100 |
| Discharge Current (A) | ≤6 | ≤10 | ≤20 | ≤30 | ≤50 | ≤100 | ≤100 |
| Weight(kg) | 1.5 | 3 | 7.5 | 11.5 | 14 | 29 | 40 |
| Dimensions(L*W*H)(mm) | 151*98*98 | 181*76*166 | 197*165*170 | 208*169*260 | 324*172*214 | 520*265*220 | 520*265*220 |
| Operation Temperature | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ | -20~60℃ |
| Housing Material | ABS | ||||||
| Protection Functions | short circuit, over charge, over discharge, over current, over temperature | ||||||
