48V 100mah Lithium Battery Storage System Home Rechargeable Energy

Product Details

Place of Origin: China

Brand Name: Huaxing

Certification: CE RoHS

Model Number: 51.2V100Ah/5KWh

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: 1100 USD

Packaging Details: 426mm*322mm*124mm/10.8Kg

Delivery Time: 15 workdays

Payment Terms: L/C, D/P, T/T

Supply Ability: 100 pcs a day

Get Best Price
Product Details
High Light:

48V 100mah Lithium Battery Storage System

,

48V 100mah 5kw lithium ion battery

,

15kwh Lithium Battery Storage System

Product Model:
CSF-5KWh/10Kwh/20Kwh-A1
Nominal Energy Capacity:
5KWh 10Kwh,15Kwh,20kwh
Battery Type:
LiFePO4(LFP)
Cell Type:
Cylindrical 32700 6.0Ah
Design Capacity:
100Ah,200Ah,300Ah.400Ah
Nominal Voltage:
51.2V
Design Years:
15 Years
Dimensions(L*W*H):
420*482*222mm
Cycle Life:
>6000 Times
Product Model:
CSF-5KWh/10Kwh/20Kwh-A1
Nominal Energy Capacity:
5KWh 10Kwh,15Kwh,20kwh
Battery Type:
LiFePO4(LFP)
Cell Type:
Cylindrical 32700 6.0Ah
Design Capacity:
100Ah,200Ah,300Ah.400Ah
Nominal Voltage:
51.2V
Design Years:
15 Years
Dimensions(L*W*H):
420*482*222mm
Cycle Life:
>6000 Times
Product Description

48V 100mah Lithium Battery Storage System Home Rechargeable Energy



48v 10kwh 200mah Ess Cabinet/Rack solar lithium battery pack for home energy storage



Product Description


Modular Design 48v Ess 5kwh Cabinet/Rack Lifepo4 Technology Solar Residential Home Energy Battery Storage System

Product Name : HOME SOLAR ENERGY STORAGE



Product Model: CSF-5KWh-A1



Product Model CSF-5KWh-A1 CSF-10KWh-A2 CSF-15KWh-A3 CSF-20KWh-A4
Nominal Energy 5KWh 10KWh 15KWh 20KWh
Battery Type LiFePO4(LFP)
Cell Model Cylindrical 32700 6.0Ah
Nominal Voltage 51.2V 51.2V 51.2V 51.2V
Design Capacity 100Ah 200Ah 300Ah 400Ah
Design Years 15 15 15 15
Dimensions(L*W*H) 420*482*222mm 660*717*522mm 660*983*522mm 660*1250*522mm
Weight 58.5Kg 117.0Kg 175.5Kg 234.0Kg
Protection Class IP55 IP55 IP55 IP55
Technical Parameter
Cycle Life ≥6000 80%DOD ≥6000 80%DOD ≥6000 80%DOD ≥6000 80%DOD
Operation Temperature Charge: 0~60℃, Discharge: -20~60℃, Storage: 0~45℃(less than 12 months)
Operating Voltage Range 40.0V-58.4V 40.0V-58.4V 40.0V-58.4V 40.0V-58.4V
Charge Voltage DC 58.4V DC 58.4V DC 58.4V DC 58.4V



Charge/Discharge Current

100A,

separate Port

100A,

separate Port

100A,

separate Port

100A,

separate Port

BMS Parameter
Communication Method CAN/RS485/RS232 CAN/RS485/RS232 CAN/RS485/RS232 CAN/RS485/RS232
Limiting 10A 10A 10A 10A



Product Introduction:



  • The IFR32700 type cylindrical LiFeP04 single cell has the advantages of small size, light weight, environmental protection,
  • High safety, long life and other advantages.
  • It is widely used in various battery combinations such as automotive batteries, start-up power supplies, energy storage, etc.

Home Energy Battery.jpg

Features:

--LiFePO4 Technology
--Longest Lifetime
--Highest Safety and Flexibility

--Modular Design
--Build-in Smart BMS
--Easy Installation
--Simple Connectors
--Widest Compatibility
--Wall-mounted and Cabinet/
--Rack Optional




Product Introduction:

  • LiFePO4 batteries are one of the most durable
    and reliable energy sources on the market.
  • Huaxing Energy is a company with
    Integration of all technologies needed
    For Energy Storage System (ESS)
    Including cathode material, lithium cell,
    BMS and system integration.
  • The LiFePO4 Lithium Ion Batteries 51.2V
    Series are designed for solar Residential
    Energy storage with low cost, high quality,
    Excellent performance.



Product Datasheet



RESIDENTIAL SOLAR ENERGY STORAGE SOLUTION

Cabinet/Rack Energy Storage Solution
smart home storage battery.jpg





Applicaitons

Energy Storage Battery.jpg







Company Information

Hunan Huaxing New Energy Technology Co., Ltd is a high quality Lithium Ion
Battery company, integrating R&D, manufacturing and sales, providing comprehensive solutions for any application.



-1000 Staff
-50,000 square meters of workshops
-3GWh annual production capacity
-300 million dollars annual turnover



Quality Management System: ISO 9001:2015, ISO 14001:2015, ISO 45001:2018
Product Safety and Performance Certificate: UL1642, IEC62619:2017, IEC62133:2017,
IEC61960:2011, CE, BIS, PSE, ROHS, UN38.3, MSDS



Our production Lines:









Our production Lines:

li ion cylindrical battery.jpg



HUAXING LIFEPO4 BATTERY PACK ROOMS:

lifepo4 cylindrical cell.jpg
