| Place of Origin: | China |
|---|---|
| Brand Name: | Huaxing |
| Certification: | CE RoHS |
| Model Number: | 51.2V100Ah/5KWh |
| Minimum Order Quantity: | 1 |
| Price: | 1100 USD |
| Packaging Details: | 426mm*322mm*124mm/10.8Kg |
| Delivery Time: | 15 workdays |
| Payment Terms: | L/C, D/P, T/T |
| Supply Ability: | 100 pcs a day |
| Product Model: | CSF-5KWh/10Kwh/20Kwh-A1 | Nominal Energy Capacity: | 5KWh 10Kwh,15Kwh,20kwh |
|---|---|---|---|
| Battery Type: | LiFePO4(LFP) | Cell Type: | Cylindrical 32700 6.0Ah |
| Design Capacity: | 100Ah,200Ah,300Ah.400Ah | Nominal Voltage: | 51.2V |
| Design Years: | 15 Years | Dimensions(L*W*H): | 420*482*222mm |
| Cycle Life: | >6000 Times | ||
| High Light: | 48v Solar Energy Storage Battery,6000 times Solar Energy Storage Battery,Energy Storage Lifepo4 Lithium Battery Pack |
||
Solar Energy Storage Batteria 48v 5kwh 10kwh 15kwh 20Kwh 100ah 200ah Lifepo4 Home Power System Lifepo4 Lithium Battery Pack
Product Name : HOME SOLAR ENERGY STORAGE
Product Model: CSF-5KWh-A1
48v 5k
wh 10kwh 15kwh 20kwh 100mah Ess Cabinet/Rack Solar Home Energy Storage Lithium Battery
Features:
--LiFePO4 Technology
--Longest Lifetime
--Highest Safety and Flexibility
--Modular Design
--Build-in Smart BMS
--Easy Installation
--Simple Connectors
--Widest Compatibility
--Wall-mounted and Cabinet/
--Rack Optional
Product Introduction:
RESIDENTIAL SOLAR ENERGY STORAGE SOLUTION
Cabinet/Rack Energy Storage Solution
| Product Model | CSF-5KWh-A1 | CSF-10KWh-A2 | CSF-15KWh-A3 | CSF-20KWh-A4 |
| Nominal Energy | 5KWh | 10KWh | 15KWh | 20KWh |
| Battery Type | LiFePO4(LFP) | |||
| Cell Model | Cylindrical 32700 6.0Ah | |||
| Nominal Voltage | 51.2V | 51.2V | 51.2V | 51.2V |
| Design Capacity | 100Ah | 200Ah | 300Ah | 400Ah |
| Design Years | 15 | 15 | 15 | 15 |
| Dimensions(L*W*H) | 420*482*222mm | 660*717*522mm | 660*983*522mm | 660*1250*522mm |
| Weight | 58.5Kg | 117.0Kg | 175.5Kg | 234.0Kg |
| Protection Class | IP55 | IP55 | IP55 | IP55 |
| Technical Parameter | ||||
| Cycle Life | ≥6000 80%DOD | ≥6000 80%DOD | ≥6000 80%DOD | ≥6000 80%DOD |
| Operation Temperature | Charge: 0~60℃, Discharge: -20~60℃, Storage: 0~45℃(less than 12 months) | |||
| Operating Voltage Range | 40.0V-58.4V | 40.0V-58.4V | 40.0V-58.4V | 40.0V-58.4V |
| Charge Voltage | DC 58.4V | DC 58.4V | DC 58.4V | DC 58.4V |
|
Charge/Discharge Current |
100A, separate Port |
100A, separate Port |
100A, separate Port |
100A, separate Port |
| BMS Parameter | ||||
| Communication Method | CAN/RS485/RS232 | CAN/RS485/RS232 | CAN/RS485/RS232 | CAN/RS485/RS232 |
| Limiting | 10A | 10A | 10A | 10A |
