Product Details
Place of Origin: China
Brand Name: Huaxing
Certification: CE/UL/ROHS/IEC/UN38.3
Model Number: HX48100-G
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiation
Packaging Details: Wood case package
Delivery Time: 20-30 days
Payment Terms: L/C, T/T
Supply Ability: 500 pks per day
Material: |
LiFePO4/Grahpite |
Nominal Voltage: |
51.2V |
Nominal Capacity: |
100AH |
Cut Off Voltage: |
40V |
Light Weight: |
About 60kg |
Steel Case Dimension: |
500*343*256.5 |
Warranty: |
2 Years |
Max Charge Voltage: |
(58.4±0.05)V |
Efficiency: |
≥97% |
BMS: |
Yes |
Material: |
LiFePO4/Grahpite |
Nominal Voltage: |
51.2V |
Nominal Capacity: |
100AH |
Cut Off Voltage: |
40V |
Light Weight: |
About 60kg |
Steel Case Dimension: |
500*343*256.5 |
Warranty: |
2 Years |
Max Charge Voltage: |
(58.4±0.05)V |
Efficiency: |
≥97% |
BMS: |
Yes |
48V 51.2V 100Ah Club Car Battery Lithium batteries golf carts LiFePO4 Battery Deep Cycle 5120Wh
IP65 48V LiFePO4 Battery For Golf Cart Marine Boat With CAN RS485
Lithium Ion Battery 51.2V 100AH For Golf Cart Marine Boat With CAN / RS485 IP65
48V 100AH LiFePo4 battery features
● More than 10 years of life cycles.
● Light-weight: Lightweight design, packed with aluminum plate and plastic components.
● They are designed to replace the lead-acid battery, which are available for drop-in replacement
● Insulation: Perfect electrical insulation, both inside and outside.
● Performance: Good heat conductivity, safety performance.
● Free maintenance.
● IP65
48V 100AH Deep cycle Lithium ion battery specification
| Item | Specification | Remark | ||
| 1 | Rated voltage | 48V | ||
| 2 | Nominal capacity | 100Ah | After standard charging, 0.33C current discharge | |
| 3 | Nominal Voltage | 51.2V | The median voltage of the standard discharge process after standard charging | |
| 4 | Max continuous charge current | 50A | 0.5C | |
| 5 | Max continuous discharge current | 50A | 0.5C | |
| 6 | Peak current | 100A(1C) | Duration: 5S | |
| 7 | Life cycles | 2000times | 25℃±2℃ | |
| 8 | Max charge Voltage | (58.4±0.05)V | @(20-45)℃ | |
| 9 | Discharge cut-off voltage | 40V | ||
| 10 | Charge time | 2h-5h | Rated charging current: 0.2C-0.5C | |
| 11 | The efficiency of charge and discharge | ≥97% | Capacity efficiency | |
| 12 | Cooling method | Nature cool | ||
| 13 | IP | IP54 | ||
| 14 | Operation temperature | Charge | (0-60)℃ | |
| Discharge | (-20-60)℃ | |||
| 15 | Relative humidity | (65±20)% | ||
| 16 | Assemble means | 16S18P | 288PCS cells | |
BMS specification
| Item | Content | Criterion |
| Charge and Discharge Port | Shared | |
| Communication | None | |
| Parallel Connection | Max 2 pcs | |
| Serial Connection | None | |
| Normal Current | Charge Current | ≤100A |
| Discharge Current | ≤100A | |
| Over charge Protection | Over charge detection voltage | 3.75±0.05V |
| Over charge detection delay time | ~1000mS | |
| Over charge release voltage | 3.55±0.05V | |
| Over charge release condition | Cut off charger | |
| Maximum charge voltage | 3.65±0.05V | |
| Over discharge protection | Over discharge detection voltage | 2.20V±0.10V |
| Over discharge detection delay time | 200ms | |
| Over discharge release voltage | 2.4V±0.10V | |
| Discharge over current protection | Discharge over current detection current | 330±30A |
| Discharge over current detection delay time | ~100±50ms | |
| Discharge over current release condition | Cut load | |
| Short circuit protection | YES | |
Main Applications:
Our LiFePO4 battery pack sets the benchmark for performance and precision in the golf cart industry. Designed to surpass the competition, these lithium batteries are available in 36V, 48V, and 72V configurations, perfectly tailored to meet the demands of the modern golf cart market.
Company Profile
Shenzhen Huaxing New Energy Technology Co.,Ltd is R&D production and sales of 32700 LiFePo4 cells and battery pack.
Our company passed ISO9001:2015 and iSO14001:2015 and ISO45001:2018
Our 32700 LFP cell passed UL1642/IEC62619/IEC61960/IEC62133/CE/PSE/BIS/Rohs/UN38.8 and MSDS.
We offer customized solutions tailored to meet the specific requirements of our customers.
Our battery pack is designed to cater to various applications, including electric vehicle projects and the replacement of lead-acid batteries. We understand that different projects may have unique specifications, which is why we offer customization options for dimensions, interfaces, and battery cell materials to suit the specific needs of customers.
Our team of experienced engineers specializes in battery design and can provide professional solutions that take into account both mechanical and electrical aspects. We work closely with our customers to understand their requirements and develop the best-suited battery solution that meets their specific needs.
To ensure customer satisfaction and confidence in our battery performance, we offer sample orders. Factories or wholesalers can test our battery's performance on electric vehicles by placing sample orders before committing to a larger batch mass production order. This allows customers to evaluate the quality, reliability, and compatibility of our batteries before making a significant investment.
