Product Details
Place of Origin: China
Brand Name: HUAXING
Certification: MSDS
Model Number: HX4824
Payment & Shipping Terms
Minimum Order Quantity: 5pcs
Price: Negotiation
Packaging Details: Carton
Delivery Time: 15days
Payment Terms: T/T, L/C
Supply Ability: 10000pcs per month
Voltage: |
51.2V |
Capacity: |
24Ah |
Max Charge Current:: |
15A |
Max Discharge Current:: |
30A |
Peak Current:: |
60A |
OEM: |
YES |
ODM: |
YES |
Life Cycles: |
Over 2000times |
Weight: |
13kg |
Application: |
E-scooter,motorcycle,e-bike |
Voltage: |
51.2V |
Capacity: |
24Ah |
Max Charge Current:: |
15A |
Max Discharge Current:: |
30A |
Peak Current:: |
60A |
OEM: |
YES |
ODM: |
YES |
Life Cycles: |
Over 2000times |
Weight: |
13kg |
Application: |
E-scooter,motorcycle,e-bike |
|
No.
|
Item
|
General Parameter
|
|
1
|
Model
|
HX4824
|
|
2
|
Standard Capacity
|
24AH
|
| 3 |
Rated Voltage
|
51.2V
|
|
4
|
Max Charge Voltage
|
58.4V
|
|
5
|
Discharge Cut Off Voltage
|
40V
|
|
6
|
Standard Charge Current
|
15A
|
|
7
|
Max Continuous Discharge Current
|
30A
|
|
8
|
Peak Instant Discharge Current
|
60A
|
|
9
|
Dimension(ABS)
|
Customized
|
|
10
|
Total weight(Approx.)
|
13kg
|
| 11 |
Operate Temperature
|
-20°C~60°C
|
|
12
|
Built-in BMS
|
YES
|
| 13 |
Cycle Times
|
2000 cycles
|
Six types for diifferent model e-scooter
Our life cycle tests for our lifepo4 battery:
Related lifepo4 battery
About us:
HUAXING NEW ENERGY is a group company.
The comparison between LFP and SLA
| LFP battery | SLA battery | Remarks | |
| Weight | high energy density: 110-120Wh/kg, leads to a smaller size and lighter weight | low energy density: 32-37Wh/kg | LFP battery is about 70% size and weight of SLA battery, lower the total weight of application |
| Cycle life | 4000 cycles and more | 400-500 cycles | LFP can be used for almost 10 years; SLA can only last for max. 2 years |
| Capacity Utilisation | 80 to 100% | 50 to 60% | Most lead acid batteries do not recommend more than 50% depth of discharge |
| Efficiency | allows for the same amp hours both in and out | voltage drops quickly and reduces the batteries' capacity while charging and rapid discharging | LFP battery has almost 100% efficiency while SLA battery has only maximum 75% efficiency |
| Voltage | maintain voltage throughout the entire discharge cycle | drops consistently throughout the discharge cycle. | A stable droping voltage allows for greater and longer-lasting efficiency of electrical components |
| Cost | Up to 8 times the cycle life compared to equivalent SLA | A low upfront cost, but a high cost of ownership in long run | Lower total cost of ownership |
| Environmental effect | clean technology, safer and more environment friendly | contains the heavy metal - lead |
